GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine

Certification
China Anhui Innovo Bochen Machinery Manufacturing Co., Ltd. certification
China Anhui Innovo Bochen Machinery Manufacturing Co., Ltd. certification
I'm Online Chat Now

GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine

GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine
GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine
GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine

Large Image :  GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine

Product Details:
Place of Origin: China
Brand Name: INNOVO
Certification: CE
Model Number: GFS2200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 25000-35000 Set
Packaging Details: Container
Delivery Time: 45-60 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5 Set Month

GFS-2200 High Speed Corrugated Board Cardboard Board Cardboard Paper Automatic Flute Lamination Machine

Description
Type: Electric Weight: 9600kg
Key: Productivity Voltage: 380
High Light:

high efficiency flute lamination machine

,

automatic servo correction flute laminator

,

2ply flute lamination machine

High Speed Corrugated Board Cardboard Paper Automatic Flute Laminating Machine



Performance characteristics

1. Lead edge feeding system. No feeding pressure structure, doesn’t damage the corrugated and enhance the pressure resistance of the corrugated.


3. Digital design realizes automatic adjustment of glue volume. Automatic adjustment of the gap of the gluing roller (automatically according to the thickness of the bottom sheet).


5. Automatic detection of top and bottom paper, automatic servo correction technology. Make the top paper automatically track and fit the bottom paper, and the accuracy is high.



Specifications

Model GFS1500 GFS2200
Max paper 1500*1500mm 2200*2200mm
Min paper 360*380mm 500*500mm
Top sheet thickness 150-800g/m2 150-800 g/m2
Bottom sheet thickness 10mm 10mm
Working speed 200m/min 200m/min
Accuracy 0.8mm 0.8mm
Total power 20kw 22kw
Dimension 15000*2400*2520mm 15700*3100*2520mm
Machine weight 8000kg 9600kg



7. Automatic lubrication pump for all main bearing ensure machine strong endurance even under heavy duty working condition.


9. Use a circulating glue system to reduce glue loss and stabilize glue adhesion effect.


11. Order memory function, one -click to transfer the previous order, convenient and fast.
