lead edge feeding paper mounting machine,
corrugated cardboard laminating paper mounting machine
LEAD EDGE FEEDING CORRUGATED CARDBOARD LAMINATING PAPER MOUNTING MACHINE
1.Top sheet Overlap feeding+non -stop correction, high speed without losing accuracy. Speed can reach 180meters/min.
2.Bottom sheet Lead edge feeding system and high flow suction adsorption feeding. The bottom paper enter the glue roller directly (without pressure by roller, it will not destroy the corrugated paper stiffness), ensuring the pressure resistance of corrugated paper, and reducing the amount of glue by 30%, which not only saves money, but also solves the phenomenon of excessive gum.
3.The front pressure roller is made of new polyfluoroethylene material, which is free to wash, and then reduce the labor strength of the operator.
|Top sheet thickness
|Bottom sheet thickness
4.The whole machine has no handle, electric adjustment, automatic detection thickness, reducing the strength of the single -order work, and increasing the effective working time.
5.Because the machine uses overlap feeding, no gap correction without stop, so the unit time output increased by 50%, which greatly reduced the power consumption of the unit time, and it was truly increasing production and energy saving.
6. Adopts top sheet aligner system to ensure high accuracy. Feeding mode can be chosen overlap sheet or separation sheet type.
7. Digital design realizes automatic adjustment of glue volume. Automatic adjustment of the gap of the gluing roller (automatically according to the thickness of the bottom sheet).
