Product Details:
|
| Bottom Paper Thickness: | 10mm | Key Selling Points: | Space Saving |
|---|---|---|---|
| Delivery Time: | 30 Days | Top Paper Thickness: | 150-800gsm |
| After Warranty Service: | Technical Department Support | Model: | GFM1500-A |
| High Light: | CE Cardboard Laminating Machine,Cardboard Laminating Machine 1500mm,High Speed Paper Laminating Machine |
||
1500mm High Speed Paper Making Corrugated Cardboard Carton Box Flute Paper Laminating Machine
Model Overview
The machine is suitable for paperboard and corrugated paper, cardboard, and motion controller and servo correction system. By using the relative positions of multiple sets of photoelectric induction paper, the servo motor on both sides of the control paper is independently compensated, and the position of the paper is tracked to make the paper and the bottom paper accurately positioned. The intelligent high-speed laminating machine is easy to oprate, and you can adjust the paper size automatically by one-touch.
This machine is a quick sticker for printing cardboard and corrugated paper. The whole machine is designed for the top paper from the feeder, the bottom paper from the leading edge feed of the composition of the automatic feeding part of the paper, and paste, press part of the composition. Suitable for cardboard and corrugated, so that cardboard more eye-catching, beautiful, high strength, is the production of high-quality cardboard of the new equipment. Widely used in food, alcohol, household appliances, light industrial products packaging.
Performance characteristics
Cardboard laminate with corrugated or cardboard laminate with cardboard.
Automatic detection of top and bottom paper, automatic servo correction technology. Make the top paper automatically track and fit the bottom paper.and the accuracy is high.
The bottom paper feeding part use imported servo motor controlling system, with Japan NITTA suction belt to ensure smooth feeding of corrugated and cardboard.
The multifunctional rack of the bottom paper are suitable for curved corrugated.
Stainless steel glue roller with fine anilox grinding to guarantee even glue coating even at min glue quantity.
Use a circulating glue system to reduce glue loss and stabilize glue adhesion effect.
One -click adjustment of the whole machine (just enter the paper size)
Video monitoring (optional).
Parameters:
| Model | GFM1500-A | GFM1700-A | GFM1900-A | GFM2200-A |
| Max size | 1500*1500mm | 1700*1700mm | 1900*1900mm | 2200*2200mm |
| Min size | 360*380mm | 360*400mm | 500*500mm | 500*500mm |
| Top Paper | 150-800g/㎡ | |||
| Bottom paper | Paper Thickness≤10mm |
|||
| Max speed | 160m/min | |||
| Power | 20kw | 20kw | 22KW | 22kw |
| Stick accuracy | ± 0.8mm | |||
